AZUCAR Westport Shipyard

If you have any questions about the AZUCAR information page below please contact us.

A General Description of Motor Yacht AZUCAR

This motor yacht AZUCAR is a 40 m 130 (ft) well sized composite boat which was produced at Westport Shipyard and conceived by Gregory C Marshall and William Garden. Sleeping 10 guests and 7 crew, motor yacht AZUCAR used to be Rejoyce; Crystal Sea which was her shipyard project name or yacht title. Finished and launched by 2001 the recent interior design reflects the design knowledge of Sheryl Guyan / Pacific Custom Interiors.

The Shipyard Work & Yacht Design with respect to Luxury Yacht AZUCAR

Gregory C Marshall was the naval architect involved in the technical superyacht composition for AZUCAR. Her interior design was realised by Sheryl Guyan / Pacific Custom Interiors. Gregory C Marshall and William Garden is also associated with the yacht general design work for this boat. the United States is the country that Westport Shipyard constructed their new build motor yacht in. After the formal launch in 2001 in Westport Wa the boat was thereafter handed over to the owner following final finishing. The hull was built out of composite. The motor yacht superstructure is fabricated extensively from composite. With a beam of 8.23 metres or 26 feet AZUCAR has fairly large interior. She has a reasonably shallow draught of 1.83m (6.6ft).

M/Y AZUCAR Main Engines And Speed:

Fitted with twin MTU diesel main engines, AZUCAR will attain a maximum speed of 29 knots. For propulsion AZUCAR has twin screw propellers (schaffran 5 blades). She also has an economical range of 3400 miles when sailing at her cruising speed of 24 knots. Her total HP is 5470 HP and her total Kilowatts are 4025. Regarding thrusters she uses Wesmar. With respect to the ship’s stabalisers she uses Naiad.

Guest Accommodation Aboard Superyacht AZUCAR:

The good sized luxury yacht M/Y AZUCAR can accommodate up to 10 people in addition to 7 crew.

A List of the Specifications of the AZUCAR:

Superyacht Name:	Motor Yacht AZUCAR
Ex:	Rejoyce; Crystal Sea
Built By:	Westport Shipyard
Built in:	Westport Wa, United States
Launched in:	2001
Length Overall:	39.62 metres / 130 feet.
Waterline Length:	35.02 (113.8 ft)
Naval Architecture:	Gregory C Marshall and William Garden, Gregory C Marshall
Designers Involved in Yacht Design:	William Garden
Interior Designers:	Sheryl Guyan / Pacific Custom Interiors
Gross Tonnes:	309
Nett Tonnes:	162
Displacement:	193
Hull / Superstructure Construction Material:	composite / composite
Owner of AZUCAR:	Unknown
AZUCAR available for luxury yacht charters:	-
Is the yacht for sale:	-
Helicopter Landing Pad:	No
Material Used For Deck:	grp-teak
The Country the Yacht is Flagged in:	United States
Official registry port is:	Kingstown
Home port:	California, USA
Max yacht charter guests:	10
Number of Crew Members:	7
The propulsion comes from two 2735 Horse Power or 2013 Kilowatts MTU. Engine Model:	12V 4000 M90 diesel.
Giving the combined power of 5470 HP /4025 KW.
Cruise Speed:	24 nautical miles per hour.
Her top Speed is around 29 nautical miles per hour.
Range in nautical Miles is 3400 at a speed of 12 knots.
Fuel Capacity:	37472 L.
Fresh water:	6132.00.
Gensets:	Northern Lights 1 times 65 kilowatts, 1 times 50 kilowatts.
Stabalisers:	Naiad.
Thrusters:	Wesmar.
Air Conditioning:	20t.
Yacht Beam:	8.23m/26ft.
Waterline Length (LWL):	35.02m/113.8ft.
Draught at deepest:	1.83m/6.6ft.

Further Information On The Yacht

20t is the AC employed in this boat. This motor yacht has a grp-teak deck.
