ELEONORA E Van der Graaf

If you have any questions about the ELEONORA E information page below please contact us.

A General Description of Sailing Yacht ELEONORA E

The work of the Van Der Graaf Bv ship building company in the Netherlands the ELEONORA E is 50 m 162 (foot) in length. Launched in 2000 her reasonably modern interior decoration confirms the realisations from Heine Deelstra & Hans Ritzema Of Gaastmeer Ship & Yacht Design and their approach to interior yacht design. Superyacht ELEONORA E is able to accommodate up to 8 people with 9 professional crew. Her former names or project names were Eleonora. She will reach a high speed of 10 knots.

Build & Naval Architecture for Luxury Yacht ELEONORA E

Nathaniel G Herreshoff was the naval architect firm involved in the technical nautical design work for ELEONORA E. Also the company Nathaniel G Herreshoff and Ship Design Gaastmeer skillfully worked on this project. Interior designer Heine Deelstra & Hans Ritzema Of Gaastmeer Ship & Yacht Design was commissioned for the overall interior ambience. the Netherlands is the country that Van Der Graaf Bv completed their new build sailing yacht in. After formal launch in 2000 in Hardinxveld-Giessendam she was then handed over to the happy owner following final finishing. Her core hull was crafted from steel. The sailing yacht main superstructure is fabricated mostly with teak. The length of the luxury yacht on deck is 41.5 (136.15 ft). With a beam of 8.2 m or 26.9 ft ELEONORA E has spacious size. She has a reasonably deep draught of 5.2m (17.06ft).

Main Engines And The Speed The S/Y ELEONORA E is Capable Of:

The 6R 124SR engine installed in the sailing yacht is built by BAUDOUIN. She is driven by a single screw propeller. The engine of the ship gives 460 horse power (or 338 kilowatts). She is equiped with 1 engines. The total output for the boat is therefore 460 HP or 338 KW.

With Superyacht ELEONORA E She Caters For The Following Passenger Accommodation Format:

Apportioning bedding for a maximum of 8 welcome guests sleeping aboard, the ELEONORA E accommodates them in style. The boat utilises approximately 9 able crew members to maintain and sail.

A List of the Specifications of the ELEONORA E:

Superyacht Name:	Sailing Yacht ELEONORA E
Ex:	Eleonora
Built By:	Van der Graaf B.V.
Built in:	Hardinxveld-Giessendam, Dutch
Launched in:	2000
Length Overall:	49.5 metres / 162.4 feet.
Waterline Length:	29.3 (96.13 ft)
Naval Architecture:	Nathaniel G Herreshoff and Ship Design Gaastmeer, Nathaniel G Herreshoff
Designers Involved in Yacht Design:	Ship Design Gaastmeer
Interior Designers:	Heine Deelstra & Hans Ritzema Of Gaastmeer Ship & Yacht Design
Displacement:	213
Hull / Superstructure Construction Material:	steel / teak
Owner of ELEONORA E:	Unknown
ELEONORA E available for luxury yacht charters:	-
Is the yacht for sale:	-
Helicopter Landing Pad:	No
Material Used For Deck:	teak
The Country the Yacht is Flagged in:	Netherlands
Official registry port is:	Rotterdam
Home port:	The Western Mediterranean, The Mediterranean
Class society used:	BV (Bureau Veritas)
Max yacht charter guests:	8
Number of Crew Members:	9
The propulsion comes from one 460 Horse Power or 338 kW Baudouin. Engine Model:	6R 124SR diesel.
Overall output:	460 HP /338 KW.
Cruising at a speed of 9 nautical miles per hour.
Her top Speed is around 10 knots.
Range in nautical Miles is 2000 at a speed of 9 knots.
Bunkering capacity:	8000 L.
Water:	12000.00.
Power generation:	Lister/Stamford 2 times 42kva.
A/C:	Cruisair.
Area of Sail:	1100 Metres Squared.
Yacht Beam:	8.2m/26.9ft.
LOD:	41.5m/136.15ft.
Waterline Length (LWL):	29.3m/96.13ft.
Draught at deepest:	5.2m/17.06ft.

Miscellaneous Yacht Details

Cruisair is the brand of air-con utilised in this boat. ELEONORA E features a teak deck.
